NSS-309L-17

Specification
AWS Specification: AWS A5.4 E309L-17
JIS Specification: N/A
Other Specification: N/A
Description
  • NSS-309L-17 is a lime-titania type electrode that gives extra low Carbon 25% Cr -12% Ni austenitic weld metal
  • Spatter free
  • Good slag detachability
  • Deposited metal has excellent resistance to the intercrystalline corrosion than that of ordinary 309 type due to extra low carbon content



TYPICAL CHEMICAL COMPOSITION OF ALL WELD METAL DEPOSITS (%):

C

Si

Mn

Ni

Cr

Mo Cu

0.02

0.68

0.80

13.1

24.2

0.05 0.10



TYPICAL MECHANICAL PROPERTIES OF ALL WELD METAL DEPOSITS:
Yield Point
N/mm2 (KSI)

Tensile Strength
N/mm2 (KSI)

Elongation
%


448  (65)

620  (90)

32



SIZE AND RECOMMENDED CURRENT RANGE: AC, DC (+)

DIAMETER (mm)

2.5

3.2

4.0

5.0

LENGTH (mm)

300

350

350

350

Current Amp

Flat

40 - 80

60 - 110

90 - 150

140 - 190

Vertical & Overhead

40 - 80

60 - 110

-

-



Welding Positions: ALL POSITIONS
Approvals: N/A

NOTE:

The information contained or otherwise referenced herein is presented only as “typical” without guarantee or warranty, and Industrial Welding Corporation expressly disclaims any liability incurred from any reliance thereon. Typical data and test results for mechanical properties, deposit, or electrode composition and other properties were obtained from a weld produced and tested according to prescribed standards and should not be assumed to be the expected results in a particular application or weldment. Actual results will vary depending on many factors, including, but not limited to, weld procedure, plate chemistry and temperature, weldment design, and fabrication methods. Users are cautioned to confirm by qualification testing, or other appropriate means, the suitability of any welding consumable and procedure before use in the intended application.

  • Welding stainless steel to carbon and low alloy steel
  • Overlaying unalloyed structural steel



  • Keep the arc length as short as possible
  • Choose the appropriate recommended welding current
